WSCAD Electrix Rocket UPDATE 2

10.07.2024

The update includes improvements to the usability and functionality of WSCAD's electrical CAD software ELECTRIX ROCKET!
Customers with an ELECTRIX ROCKET subscription license or a maintenance contract can install Update 2 for free via the pop-up window after starting ELECTRIX ROCKET or via the ELECTRIX main menu Help | Internet Update.
If you are still working with the previous version, WSCAD SUITE, we recommend upgrading to WSCAD ELECTRIX.

Key innovations of Update 2:

• Better user experience: You can now easily copy the format from one symbol to another! The status bar now displays useful information while zooming or moving the page.
• Engineering modules: The number of levels for multi-story terminals has been increased from 10 to 50! And there are no more upper limits for boreholes and threads coordinates.
• Interface and management: Added an option to remove projects from the Project Explorer without deleting them from the directory.
• CE module (Cabinet Engineering): On Cabinet pages, all graphic elements of a symbol are displayed correctly. If the symbol is loaded into the Symbol Editor, the graphic elements can be edited correctly.
• Better integration and export: Improved support for special characters in the Weidmüller M-Print PRO export and enhanced functionality for the PHOENIX PROJECT export.

Check out all the details about the Update 2 here.

Download the free DEMO version by clicking the button.
